Suitable for use on aluminium, timber and
steel doors
Compact case size & clean aesthetics
Maintains a magnetic holding force of at
least 250kg (550lbs)
Strong durability & low maintenance
Fit any aluminium, timber or steel door
CE marked to EMC Directive
Successfully completed 30 minute fire test
(not 262)
Specification:
| Single Magnet: |
25mm x 250mm x 42mm (261
models). |
|
| | Armature: |
11.3mm x 160mm x 36mm (2 no. for
double magnet |
| Nominal Holding Force: |
250kg (550lbs). |
| Supply Voltage: |
12 or 24vDC (±15%). Dual
coil. |
| Nominal Current: |
480mA @ 12vDC, 240mA @ 24vDC. Built-in
voltage spike suppressor. |
| Monitoring: |
Relay dry contact with LED. Integral
on 261 models, compact isolated unit on 262-005. |
| Door Gap: |
Maximum 3mm (1/8"). |
| 261 Positioning: |
Outward opening - surface mounted to
door frame header. Inward opening - door frame header using 'L'
& 'Z' brackets. |
| |
| Magnet Housing: |
Brushed satin aluminium. |
| Note: |
To achieve immediate release, it is
important that the release switch breaks the circuit on the
positive supply to the magnet. |
|
Has a security pin feature to help prevent
unauthorised brackets removal of the magnet from the door frame
fixing plate
Available for outward and inward opening
door applications
User selectable dual voltage - 12 or 24vDC
Also available as a double magnet model
Surface or mortice version
Monitoring available (Hall Effect)
Built in voltage spike suppressor
|
